Custom Shell & Tube
Custom Shell & Tube
"Before the production of standard products, there were engineering products designed for each heat exchanger application. Our Basco tube heat exchangers have met all thermal transfer needs for over sixty years. Our experienced design and engineering team is ready to provide the best equipment with the best intermediaries in the industry to address the challenge of thermal transfer."
PERFORMANCE NOTES
- * We manufacture all types of TEMA heat exchangers.
- * Shell dimensions range between 6" (150mm) and 144" (3658mm) typically, but sometimes with smaller or larger shells.
- * Maximum tube length is 50 ft (15.2 meters). Tubes come in configurations of three or square, finned or bare, BASCOR and thin plate.
- * Heads are produced in cast iron, bronze, or 316 S/S; Cage in steel, 304 S/S, or 90/10 CuNi.
- * There are also designs with 1-pass, 2-pass, and 4-pass configurations."
CERTIFICATES
- * CE Directive for Pressure Equipment (PED) (97/23/EC)
- * Chinese Safety Quality License for Boilers and Pressure Vessels
- * Australia AS1210
- * Singaporean Law
- * Malaysian DOSH Reference
- * Canada CRN, all cities
- * Indian Boiler Regulations (IBR)
- * Polish Certificate
- * API 614, 660, 618"
